Feature:
*High Bs, low Br. Bigger flux gain △B, minimizing the volume of transformers
*High permeability, low coercive force. Low exciting power, high efficiency.
*Low core loss. Reducing temp.-rising,increasing efficiency.
*High curie temperature ,superior temperature stability.
*Continuous working temperature range: －５０～+130℃.
Feature:
*High Bs, low Br. Bigger flux gain △B, minimizing the volume of transformers
*High permeability, low coercive force. Low exciting power, high efficiency.
*Low core loss. Reducing temp.-rising,increasing efficiency.
*High curie temperature ,superior temperature stability.
*Continuous working temperature range: －５０～+130℃.
Application:
*Switched mode power supply. such as ups.
*HF welding equipment. Such as inverter welding machine, plasma.
*Electrolytic and plating power supply.
*Charging power. Such as EV car, charging pile , PV inverter.
*Medical device. Such as x-ray ,laser power supply
*Induction heating system. Such as Mid-frequency furnace.
Comparison:
| ITEM | Symbol & Unit | Nanocrystalline | Mn-Zn ferrite |
| Material Type | - | 1k107A | PC40(TDK) |
| Saturation Flux Density | Bs (T) | 1.2 | 0.51 |
| Resicual Induction | Br (T) | ≤0.2 | 0.1 |
| Real. Permeability (at 10khz) | Gs/Oe | Ca.20,000 | Ca.2300 |
| Coercive Force | Hc(A/m) | 1.6 | 14 |
| Core Loss (20KHZ/0.2T) | Pfe (W/Kg) | ≤8 | ≤15 |
| Core Loss (20KHZ/0.5T) | Pfe (W/Kg) | ≤25 | bad |
| Core Loss (100KHZ/0.3T) | Pfe (W/Kg) | ≤110 | bad |
| Magnetostriction | λs (ppm) | ≈0 | -1.1 |
| Density | d（g/cm³) | 7.25 | 4.8 |
